UPS 2200VA / 1320W POWERWALKER VI 2200 RLE, LCD Display 4x IEC C13, USB, RS232, 10121100

Опис

Model name: POWERWALKER VI 2200 RLE Specifications: Type: Line-Interactive (VI) Phases (IN-OUT): 1-1 Form Factor: Rack Rack Units [U]: 2U Power Capacity: 2200VA / 1320W Output Power Factor: 0.60 Input: Input Voltage Range: 165-290 VAC Frequency Range: 45Hz – 65Hz Output: Waveform: Pure Sine Wave VA: 2200 Nominal Output Voltage: 230 VAC THDv: ≤3% @ 100% linear load, ≤5% @ 100% non-linear load Frequency (Battery Mode): ±0.5Hz Output Power Factor: 0.60 Input & Output Connectors: Input Connector: C14 IEC C13: 4 Technical Details: LINE Mode Efficiency: 98.0% (Full Load) Battery Mode Efficiency: 80.0% (Full Load) Transfer Time (AC / Line Mode to Battery Mode): 4 ms typical Data Line Protection: RJ-11 Port, RJ-45 Port (100 mbit) Additional Features: LCD Display, Circuit Breaker Reset, Generator Compatible, EPO – Emergency Power Off, HID – Human Interface Device, AVR – Automatic Voltage Regulator, Energy Saving Function Batteries and Autonomy: Batteries: 2x 12.0V / 9.0Ah DC Voltage: 2x 12.0V Recharge Time: 4h to 90% Full Load Backup Time: 1.1 min Half Load Backup Time: 7.1 min Charger: 1A Communication: Communication: USB Type B – for Monitoring Software, RS-232, Management Card Slot Software: PowerMaster Management and Environment: Noise Level: < 50dB Fan Logic: Fan Off: Line Mode Fan On: Battery Mode, AVR ON, Battery Charging Temperature: 0°C – 40°C Humidity: 0% – 90% RH (non-condensing) IP: IP 20
