MB 1151 H310CM-DVS ASROCK, 2xDDR4 2666MHz, DVI-D, VGA, PCIex16, PCIex1, 4xSATAIII, 4xUSB 3.1, 4xUSB2.0, 7.1 Channels

Опис

Model Name: ASROCK H310CM-DVS Specification Unique Feature ASRock Super Alloy Sapphire Black PCB High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update & APP Shop CPU Supports 9th and 8th Gen Intel® Core™ Processors (Socket 1151) Supports CPU up to 95W 4 Power Phase design Supports Intel® Turbo Boost 2.0 Technology Chipset Intel® H310 Memory Dual Channel DDR4 Memory Technology 2 x DDR4 DIMM Slots Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory Max. capacity of system memory: 32GB* Supports Intel® Extreme Memory Profile (XMP) 2.0 15μ Gold Contact in DIMM Slots BIOS 128Mb AMI UEFI Legal BIOS with multilingual GUI support ACPI 6.0 Compliant wake up events SMBIOS 2.7 Support DRAM, PCH 1.05V Voltage Multi-adjustment Graphics Supports Intel® UHD Graphics Built-in Visuals DirectX 12 HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 Dual graphics output: Support DVI-D and D-Sub ports by independent display controllers Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz Supports HDCP 2.2 with DVI-D Port Audio 7.1 CH HD Audio (Realtek ALC887/897 Audio Codec) Supports Surge Protection LAN PCIE x1 Gigabit LAN 10/100/1000 Mb/s 1 x Realtek RTL8111H Supports Wake-On-LAN Supports Lightning/ESD Protection Supports Energy Efficient Ethernet 802.3az Supports PXE Slots 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode) 1 x PCI Express 2.0 x1 Slot Storage 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug Connector 1 x TPM Header 1 x Chassis Intrusion and Speaker Header 1 x CPU Fan Connector (4-pin)* 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)** 1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector 1 x Front Panel Audio Connector 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection) Rear Panel I/O 1 x PS/2 Mouse/Keyboard Port 1 x D-Sub Port 1 x DVI-D Port 4 x USB 2.0 Ports (Supports ESD Protection) 2 x USB 3.1 Gen1 Ports (Supports ESD Protection) 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software ASRock Motherboard Utility (A-Tuning) ASRock XFast LAN UEFI ASRock EZ Mode ASRock Full HD UEFI ASRock My Favorites in UEFI ASRock Instant Flash ASRock Internet Flash Support CD Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories Quick Installation Guide, Support CD, I/O Shield 2 x SATA Data Cables Hardware Monitor Temperature Sensing: CPU, Chassis/Water Pump Fans Fan Tachometer: CPU, Chassis/Water Pump Fans Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans CASE OPEN detection Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor Micro ATX Form Factor: 7.5-in x 7.4-in, 19.1 cm x 18.8 cm Solid Capacitor design OS Microsoft® Windows® 10 64-bit / 11 64-bit Certifications FCC, CE ErP/EuP ready (ErP/EuP ready power supply is required)
