MB 1700 Z790 D GIGABYTE, 4xDDR5 7600MHz(OC), PCIex16 5.0, 2xPCIex16 4.0, 2xPCIex1, 3xM.2, 6xSATAIII, DP, HDMI, 2.5GbE LAN

Опис

Model name: GIGABYTE Z790 D Specification CPU LGA1700 socket: Support for 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold, and Celeron® Processors L3 cache varies with CPU Chipset Intel® Z790 Express Chipset Memory 14th and 13th Gen Intel® Core™ i9/i7: DDR5 up to 7600(O.C.) MT/s 13th Gen Core™ i5/i3 and 12th Gen Intel® Core™: DDR5 up to 4800/4400 MT/s 4 x DDR5 DIMM slots, max 256 GB Supports ECC/non-ECC, XMP memory modules Onboard Graphics 1 x HDMI (4096x2160@60 Hz) 1 x DisplayPort (4096x2304@60 Hz) Audio Realtek® Audio CODEC, High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN Realtek® 2.5GbE LAN chip Expansion Slots CPU: 1 x PCIe 5.0 x16 Chipset: 1 x PCIe 4.0 x4, 2 x PCIe 3.0 x1 Storage Interface CPU: 1 x M.2 (PCIe 4.0 x4/x2 SSD support) Chipset: 2 x M.2, 4 x SATA 6Gb/s RAID support for NVMe and SATA devices USB USB Type-C, USB 3.2 Gen 1/2, and USB 2.0 ports Internal I/O Connectors Power connectors, fan headers, SATA connectors Front panel headers, TPM header Back Panel Connectors USB ports, HDMI, DisplayPort, RJ-45, audio jacks I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage, temperature, and fan speed detection Fan speed control BIOS 256 Mbit flash, AMI UEFI BIOS Bundled Software Norton® Internet Security (OEM) Operating System Supports Windows 11/10 64-bit Form Factor ATX Form Factor: 30.5cm x 24.4cm
