NET Switch CUDY 16-port Gigabit rackmount (19") Default/VLAN/Extend Modes, GS1016L

Опис

Model name: CUDY GS1016L Specifications: Interfaces: Gigabit RJ45 Ports: 16 Shielded RJ45 Port: True Extend Mode Ports: #1~#14 VLAN Mode Ports: #1~#14 LED: Power Speed/Link/ACT of Each Ethernet Port Physical Buttons: VLAN/Default/Extend DIP Switch Performance: Copper Speed and Distance: Cat. 3 or higher cable: 100 meters at 10 Mbps Cat. 5 or higher cable: 100 meters at 100 Mbps Cat. 5e or higher cable: 100 meters at Gigabit Cat. 5e or higher cable: 250 meters at 10 Mbps Copper Speed and Distance Note: 250-meter transmission is only available on the Extend Mode ports when the Extend Mode is activated. MAC Address Table: 8192 Max Switching Capacity: 32 Gbps Max Forwarding Rate: 23.808 Mpps Jumbo Frame: 15 KB Packet Buffer: 4 Mbit Power: Basic Power Saving: True Power Methods: AC AC: 90-260V~, 50/60Hz Max Power Consumption: 7.8W Idle Power Consumption: 4.5W Switching: 802.3 Protocols: 802.3x Flow Control 802.3i 10BASE-T 802.3u 100BASE-TX 802.3ab 1000BASE-T 802.1 Protocols: 802.1p: LAN Layer 2 QoS/CoS L2 Features: IGMP Snooping Loop Prevention Loop Detection DSCP QoS 802.1p QoS Reliability: Grounding Methods: Three-Prong Plug Grounding Point EMS: IEC/EN 61000-4-2, Level 3 ESD: Contact: 6kV; Air: 8kV IEC/EN 61000-4-5, Level 4 Surge: Power: DM 2kV, CM 4kV; RJ45: CM 4kV Environment: Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing Mechanical: Dimension: 440×180×44 mm (17.32×7.09×1.73 inches) Product Weight: 1597.9 g (56.36 oz.) Casing Material: Metal Installation: Desktop Rackmount via Brackets
