PSU 450W BE QUIET! SYSTEM POWER 11 80 Plus BRONZE, BP009EU

Опис

Model name: BE QUIET! SYSTEM POWER 11 Specification : Cables & Connectors: Sleeved Cables: P24 Flat Cables: P4+4, PCIe, drives Maximum Cable Length: 55 cm Cable Length to Motherboard: 79 cm Number of Cables: 5 ATX-Motherboard (20+4-pin): 1 P4+4 (CPU): 1 PCI-e 6+2-pin (GPU): 2 SATA: 5 PATA: 1 Input: Voltage: 200 - 240 V AC Frequency: 50 Hz Current: 4 A Power Factor at 100% Load: >0.98 Modern Standby: ✓ Power Consumption in Standby: <0.1 W Operating Temperature: up to 40 °C General: Continuous Power: 450 W Form Factor: ATX 3.1 EPS 12V Form Factor: Version 2.92 Topology: Double forward + DC-DC Average Lifetime: >100,000 h @ 25°C 80 PLUS Certification: Bronze Efficiency: 2% load: 61.3% 10% load: 82.4% 20% load: 87.4% 50% load: 89.0% 100% load: 85.9% Fan & Cooling: Fan: Silence-optimized be quiet! fan Fan Size: 120 mm Bearing Technology: Rifle Motor Technology: 4-pole fan motor Max Fan Speed: 1800 rpm Noise Levels: 10% load: 10.5 dB(A) 20% load: 10.6 dB(A) 50% load: 10.8 dB(A) 100% load: 19.1 dB(A) Output: 12V Single Rail Operation: ✓ +3.3V: 20 A +5V: 20 A +12V1: 37.5 A -12V: 0.3 A +5Vsb: 3 A Max Combined Power 12V: 450 W Max Combined Power 3.3V + 5V: 110 W Hold-up Time 100% Load: 16.86 ms Hold-up Time 80% Load: 20.92 ms Power Good Signal: 100 - 150 ms
