NET INJECTOR CUDY POE+/POE 30W POE200

Опис

Model Name: CUDY POE200 Specification : Model: POE200 No. of channels: 1 Pass Through Data Rates: 10/100/1000Mbps Power over Ethernet Output: Pin Assignment and Polarity: 1/2 (-), 3/6 (+) Output Power Voltage: 54VDC User Port Power: 30W max Input Power Requirements: AC Input Voltage: 100 to 240 VAC AC Input Current: 0.5A 100-240 VAC AC Frequency: 50 to 60 Hz Dimensions: 121mm x 50mm x 36mm Indicators: System Indicator: AC Power User Indicator: Channel Power Connectors: Shielded RJ-45, EIA 568A and 568B Protection: Over current protection Over load protection Over voltage protection Anti-interference protection Environmental Conditions: Operating Ambient Temperature: -40 to 40℃ Operating Humidity: Maximum 85%, Non-condensing Storage Temperature: -40 to 50℃ Storage Humidity: Maximum 90%, Non-condensing
