NET Switch CUDY 5-port Gigabit 4xPOE+ 120W, 1x SFP, GS1005PTS1

Опис

Model name: CUDY GS1005PTS1 Specification : Interfaces: Physical Buttons: VLAN/Default/Extend DIP Switch 1.25G SFP Slots: 1 Gigabit RJ45 Ports: 1 Gigabit RJ45 PoE Ports: 4 Max Power on a Single PoE Port: Port 1: 60W Port 2~4: 30W PoE Port Notes: PoE port #1 supports 802.3at 60W output, and the rest support 30W 802.3at/af standards. Extend Mode Ports: #3~#4 VLAN Mode Ports: #1~#4 LED Indicators: Power DIP Mode (SW) Link/ACT of Each Ethernet Port Power Input: AC Inlet Performance Copper Speed and Distance: Cat. 3 or higher cable: 100 meters at 10 Mbps Cat. 5 or higher cable: 100 meters at 100 Mbps Cat. 5e or higher cable: 100 meters at Gigabit Cat. 5e or higher cable: 250 meters at 10 Mbps Copper Speed and Distance Note: 250-meter transmission is only available on the Extend Mode ports. Optical Spec and Distance: Depends on the Installed Optical Module MAC Address Table: 2048 Max Switching Capacity: 12 Gbps Max Forwarding Rate: 8.928 Mpps Jumbo Frame: 9 KB Packet Buffer: 1 Mbit Power: Power Methods: AC AC: 100-240V 50/60Hz Max Power Consumption: 120W Max Power Excluding PoE: 5W Switching 802.3 Protocols: 802.3i 10BASE-T 802.3u 100BASE-TX 802.3ab 1000BASE-T 802.3x Flow Control 802.3af PoE 802.3at PoE Reliability: Grounding Methods: Three-Prong Plug Environment: Operating Temperature: -10~50 ℃ (14~122 ℉) Storage Temperature: -40~70 ℃ (-40~158 ℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing
