NET Switch CUDY 24-port Gigabit rackmount (19"), GS1024L

Опис

Model name: CUDY GS1024L Specifications: Interfaces Gigabit RJ45 Ports: 24 Shielded RJ45 Port: True Extend Mode Ports: #1~#22 VLAN Mode Ports: #1~#22 LED Indicators: Power, Speed/Link/ACT of Each Ethernet Port Physical Buttons: VLAN/Default/Extend DIP Switch Power Input: AC Inlet Performance Copper Speed and Distance: Cat. 3 or higher cable: 100 meters at 10 Mbps Cat. 5 or higher cable: 100 meters at 100 Mbps Cat. 5e or higher cable: 100 meters at Gigabit Cat. 5e or higher cable: 250 meters at 10 Mbps Note: 250-meter transmission is only available on Extend Mode ports when Extend Mode is activated. MAC Address Table: 8192 Max Switching Capacity: 48 Gbps Max Forwarding Rate: 35.712 Mpps Jumbo Frame: 15 KB Packet Buffer: 4 Mbit Power Basic Power Saving: True Power Methods: AC AC Input: 90-260V~, 50/60Hz Max Power Consumption: 11W Idle Power Consumption: 6.8W Switching Protocols 802.3x Flow Control 802.3i 10BASE-T 802.3u 100BASE-TX 802.3ab 1000BASE-T 802.1 Protocols 802.1p: LAN Layer 2 QoS/CoS L2 Features IGMP Snooping Loop Prevention Loop Detection DSCP QoS 802.1p QoS Reliability Grounding Methods: Three-Prong Plug, Grounding Point EMS: IEC/EN 61000-4-2, Level 3 ESD: Contact: 6kV; Air: 8kV IEC/EN 61000-4-5, Level 4 Surge: Power: DM 2kV, CM 4kV; RJ45: CM 4kV Environment Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~ 104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing
