NET Switch CUDY 8-port 10/100M, FS1010PG 8X POE+ 2X GIGABIT UPLINK 120W, FS1010PG STEEL CASE, BLACK,

Опис

Model name: CUDY FS1010PG Specification : Interfaces Gigabit RJ45 Ports: 2 10/100 Mbps RJ45 Ports: 8 10/100 Mbps RJ45 PoE Ports: #1~#8 Max Power on a Single PoE Port: 30W PoE Port Notes: The PoE ports comply with IEEE 802.3at/af standards. Extend Mode Ports: #1~#8 VLAN Mode Ports: #1~#8 LED Indicators: Power Indicators: Link/ACT of Each Ethernet Port Indicators: DIP Mode (SW) Power Interfaces: AC Inlet Physical Buttons: VLAN / Default / Extend DIP Switch Performance Copper Speed and Distance: Cat. 3 or higher cable: 100 meters at 10 Mbps Cat. 5 or higher cable: 100 meters at 100 Mbps Cat. 5e or higher cable: 100 meters at Gigabit Cat. 5e or higher cable: 250 meters at 10 Mbps Copper Speed and Distance Note: Gigabit speed is only available on the uplink ports. 250-meter transmission is only available on the Extend Mode ports when the Extend Mode is activated. MAC Address Table: 2048 Max Switching Capacity: 5.6 Gbps Max Forwarding Rate: 4.166 Mpps Packet Buffer: 2 Mbit Power Power Methods: AC Power Input: 100-240V~, 50/60Hz Power Supply: 120W Max Power Excluding PoE: 5W Switching 802.3 Protocols: 802.3i 10BASE-T 802.3u 100BASE-TX 802.3ab 1000BASE-T 802.3x Flow Control 802.3af PoE 802.3at PoE Reliability Grounding Methods: Three-Prong Plug Environment Operating Temperature: 0~40 ℃ (32~104 ℉) Storage Temperature: -40~70 ℃ (-40~158 ℉) Operating Humidity: 10~90% non-condensing Storage Humidity: 10~95% non-condensing
