NET ROUTER WIRELESS DUAL BAND AC1200 4G LTE CUDY LT500D, w/4 antennas, 1x WAN/LAN port, 3x LAN ports, LT500D

Опис

Model Name: 4G AC1200 Wi‑Fi Router with Detachable Antennas LT500D 4G Cat.4 LTE router with AC1200 dual‑band Wi‑Fi · Up to 150 Mbps download 4 × Fast Ethernet ports · Nano SIM slot · Detachable LTE antennas · Cudy Mesh & VPN support Features 4G Cat.4 LTE router with max 150 Mbps DL and 50 Mbps UL (region‑dependent) AC1200 4‑stream dual‑band Wi‑Fi 5 with up to 867 Mbps (5 GHz) + 300 Mbps (2.4 GHz) Two detachable cellular antennas (SMA female) for better LTE reception and placement 2 × external Wi‑Fi antennas with internal FEM/PA/LNA and beamforming for extended coverage up to 170 m (open space) 4 × Fast Ethernet ports, with 1 configurable as WAN/LAN and 3 as LAN ports Cudy Mesh support for seamless whole‑home Wi‑Fi when used with compatible devices Built‑in VPN server and client functions for secure remote access and privacy Cudy App and cloud control for easy remote management and monitoring WPS and reset buttons, plus status LEDs for system and Ethernet link/activity Wall performance optimised for typical homes: up to two wooden walls or one concrete wall Specification Product type: 4G LTE Wi‑Fi router CPU: 580 MHz single‑core MIPS24KEC Flash / ROM: 16 MB (128 Mbit) NOR DDR / RAM: 128 MB (1 Gbit) DDR2 Cellular standard: 4G Cat.4 Cellular antennas: 2 × detachable (SMA female) SIM slot: 1 × Nano SIM Advanced cellular: DL 2×2 MIMO Available versions: EU, US, AU EU version – suitable region: Europe, Middle East, Africa EU max DL speed: 150 Mbps (LTE‑FDD), 130 Mbps (LTE‑TDD) EU max UL speed: 50 Mbps (LTE‑FDD), 30 Mbps (LTE‑TDD) EU bands: LTE‑FDD B1/3/5/7/8/20/28; LTE‑TDD B38/40/41; WCDMA B1/5/8 Wi‑Fi standard: Wi‑Fi 5 (802.11ac), dual‑band 5 GHz Wi‑Fi speed: 867 Mbps 2.4 GHz Wi‑Fi speed: 300 Mbps 5 GHz Wi‑Fi streams: 2 spatial streams 2.4 GHz Wi‑Fi streams: 2 spatial streams Wi‑Fi antennas: 2 × external 5 GHz antenna gain (max): 4.8 dBi 2.4 GHz antenna gain (max): 5.19 dBi FEM / PA/LNA: 5 GHz – 2 × internal; 2.4 GHz – 2 × internal Beamforming: Yes Range performance (max): 170 m (558 ft) in open space Wall performance: Two wooden walls < 10 cm or one concrete wall < 20 cm Ethernet ports: 4 × 10/100 Mbps RJ45 Ethernet notes: 1 × RJ45 is WAN/LAN configurable; 3 × LAN Buttons: WPS button, Reset button LED indicators: System; Speed/Link/ACT of Ethernet ports Software features: Cudy Mesh, VPN server & client, Cudy App, Cloud control
