NET ACCESS POINT CUDY AP3600-P, BE3600 2.5GbE PoE, 5-Stream Dual-Band Wi-Fi 7, 130m2, wall/ceiling-mount, (POE Adapter included), AP3600-P

Опис

Model Name: BE3600 2.5G Wi‑Fi 7 Access Point AP3600 1.0 Wi‑Fi 7 BE3600 dual-band access point · 2.5G PoE in + 1G PoE out Up to 2882 + 688 Mbps · Covers ~120 m² · Up to 200 connected devices Features Wi‑Fi 7 BE3600 4‑stream dual-band AP with up to 2882 Mbps (5 GHz) + 688 Mbps (2.4 GHz) Powered by a Broadcom 2.0 GHz quad‑core ARM Cortex‑A7 CPU for high concurrent client performance Covers up to 120 m² (1,300 ft²) with support for around 200 connected devices 1 × 2.5 GbE PoE in and 1 × GbE PoE out for flexible deployment and daisy‑chaining Supports 802.3at PoE, passive PoE and 12 V DC input 4 × internal high‑gain antennas with beamforming and integrated FEM/PA/LNA Multi‑AP management, watchdog and schedule reboot for reliable, scalable networks Captive portal and multi‑SSID for guest access and segmenting user groups Optimised range up to 220 m in open space, with strong wall penetration performance Available as AP3600 (no adapter) or AP3600_P (PoE adapter included) Specification Product type: Wi‑Fi 7 access point Model: AP3600 1.0 (BE3600 2.5G Wi‑Fi 7) CPU: 2.0 GHz quad‑core ARM Cortex‑A7 (Broadcom) Flash / ROM: 128 MB (1 Gbit) NAND DDR / RAM: 512 MB (4 Gbit) DDR3L Wi‑Fi standard: Wi‑Fi 7, dual band 5 GHz Wi‑Fi speed: 2882 Mbps 2.4 GHz Wi‑Fi speed: 688 Mbps 5 GHz Wi‑Fi streams: 2 spatial streams 2.4 GHz Wi‑Fi streams: 2 spatial streams Wi‑Fi antennas: 4 × internal 5 GHz antenna gain (max): 5.5 dBi 2.4 GHz antenna gain (max): 5.4 dBi FEM / PA/LNA: 5 GHz – 2 × internal; 2.4 GHz – 2 × internal Beamforming: Yes Coverage (typical): ~120 m² (1,300 ft²) Range performance (max): 220 m (722 ft) in open space Wall performance: Two wooden walls < 10 cm; or one concrete wall < 20 cm; or two concrete walls < 10 cm Recommended clients: Up to ~200 connected devices 2.5G RJ45 ports: 1 (PoE in) Gigabit RJ45 ports: 1 (PoE out) Ethernet notes: Accepts PoE powering LED indicators: System Buttons: Reset button Power input type: DC jack, PoE via Ethernet port Power methods: 12 V DC, Passive PoE, 802.3at/af PoE DC input: 12 V⎓1 A Passive PoE input: 48–57 V⎓ PoE input: 802.3at/af Max power consumption: 10 W Power adapter in box: AP3600 – none; AP3600_P – 48 V passive PoE adapter (100–240 V~, 50/60 Hz input) Advanced reliability: Hardware watchdog EMC: ESD contact 4 kV, air 8 kV Operating temperature: 0–40 ℃ (32–104 ℉) Storage temperature: -40–70 ℃ (-40–158 ℉) Humidity (operating): 10–90% RH (non‑condensing) Humidity (storage): 5–95% RH (non‑condensing) Certifications: FCC, CE Management features: Multi‑AP management, Watchdog, Schedule reboot, Captive portal, Multi‑SSID
