MB AM5 X670-P PRIME WIFI ASUS 4xDDR5 6400Mhz(O.C),HDMI,DP, 3xPCIex16 4.0, PCIex1, 3xM.2, 6xSATAIII, WiFi 6,BT 5.2

Опис

Model name: ASUS X670-P PRIME WIFI Specification : CPU: AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors* Chipset: AMD X670 Memory: 4 × DIMM, Max. 128GB, DDR5 6400+(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000/4800, ECC & Non-ECC, Un-buffered Dual Channel Memory Architecture Supports AMD EXPO (Extended Profiles for Overclocking) OptiMem II Graphics: 1 × DisplayPort (max 8K@60Hz, DisplayPort 1.4) 1 × HDMI® port (max 4K@60Hz, HDMI® 2.1) Expansion Slots: CPU: 1 × PCIe 4.0 x16 (x16 mode) Chipset: 2 × PCIe 4.0 x16 (x4 mode) 1 × PCIe 3.0 x1 (shares bandwidth with SATA6G_3/4 ports) Storage: 3 × M.2 slots (Key M) 6 × SATA 6Gb/s ports RAID support via AMD RAIDXpert2 (NVMe RAID 0/1/10, SATA RAID 0/1/10) M.2 slot details: M.2_1: PCIe 5.0 x4 (2242/2260/2280) M.2_2: PCIe 4.0 x4 (2242/2260/2280/22110) M.2_3: PCIe 4.0 x4 (2242/2260/2280) Ethernet: 1 × Realtek 2.5Gb Ethernet Wireless & Bluetooth: Wi-Fi 6, 2x2 (802.11 a/b/g/n/ac/ax), 2.4/5 GHz Bluetooth v5.2 USB Ports: Rear (10): 1 × USB 3.2 Gen 2x2 Type-C, 3 × USB 3.2 Gen 2 Type-A, 4 × USB 3.2 Gen 1 Type-A, 2 × USB 2.0 Type-A Front (9): 1 × USB 3.2 Gen 1 Type-C, 2 × USB 3.2 Gen 1 headers (support 4 ports), 2 × USB 2.0 headers (support 4 ports) Audio: Realtek 7.1 Surround Sound HD Audio CODEC Features: Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-bit/192 kHz playback Audio Shielding, Premium capacitors, Dedicated PCB layers Back Panel I/O: 1 × USB 3.2 Gen 2x2 Type-C, 3 × USB 3.2 Gen 2 Type-A, 4 × USB 3.2 Gen 1 Type-A, 2 × USB 2.0 Type-A 1 × DisplayPort, 1 × HDMI® port 1 × Wi-Fi module, 1 × Realtek 2.5Gb Ethernet 3 × Audio jacks, 1 × BIOS FlashBack™ button, 1 × PS/2 Keyboard/Mouse combo port Internal I/O Connectors: Fan & Cooling: 1 × 4-pin CPU Fan, 1 × CPU OPT Fan, 1 × AIO Pump, 3 × Chassis Fan headers Power: 1 × 24-pin Main Power, 1 × 8-pin +12V, 1 × 4-pin +12V Storage: 3 × M.2 slots, 6 × SATA 6Gb/s ports USB: 1 × USB 3.2 Gen 1 Type-C, 2 × USB 3.2 Gen 1 headers (4 ports), 2 × USB 2.0 headers (4 ports) Miscellaneous: 3 × Addressable Gen 2 headers, 2 × Aura RGB headers, 1 × Clear CMOS, 1 × COM, 1 × Front Panel Audio, 1 × S/PDIF Out, 1 × SPI TPM, 1 × 20-5 pin System Panel, 1 × Thunderbolt™ (USB4®) header Special Features: ASUS 5X PROTECTION III: DIGI+ VRM, ESD Guards, LANGuard, Overvoltage Protection, Safeslot Core+, Stainless-Steel Back I/O ASUS Q-Design: M.2 Q-Latch, Q-DIMM, Q-LED Core, Q-Slot ASUS Thermal Solution: M.2 heatsink, VRM heatsink design ASUS EZ DIY: BIOS FlashBack™ button & LED, ProCool Aura Sync: Aura RGB headers, Addressable Gen 2 headers Software Features: Armoury Crate: Aura Creator, Aura Sync, Fan Xpert 4 with AI Cooling II, Power Saving AI Suite 3: TurboV EVO, DIGI+ VRM, PC Cleaner ASUS CPU-Z, MyASUS, Norton Antivirus (Trial), WinRAR UEFI BIOS: 256 Mb Flash ROM, UEFI AMI BIOS, ASUS CrashFree BIOS 3, ASUS EZ Flash 3 Manageability: WOL by PME, PXE Accessories: 2 × SATA 6Gb/s cables, Wi-Fi antennas, I/O Shield, Rubber & Screw packages for M.2 SSD, User guide Operating System: Windows® 11, Windows® 10 64-bit
