MB 1200 Z590MHP BIOSTAR 2xDDR4 4000MHz(O.C.), HDMI, VGA, PCIex16, 2xPCIex1,4xSATA,1xM.2, 2xUSB 3.2, 4xUSB 2.0, COM port

Опис

Model Name: BIOSTAR Z590MHP Specification : Chipset: Intel Z590 CPU SUPPORT: Socket 1200 for 10th / 11th Gen Intel Core™, Pentium and Celeron processors MEMORY: Supports Dual Channel DDR4: 4000(OC)/ 3866(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3200/ 2933/ 2800/ 2666/ 2400/ 2133 2 x DDR4 DIMM Memory Slot: Max. Supports up to 64 GB Memory Each DIMM supports non-ECC: 4/8/16/32 GB DDR4 module INTEGRATED VIDEO: By CPU model Supports DX12 Supports HDCP STORAGE: 4 x SATA III Connector (6Gb/s) Supports AHCI, RAID 0, 1, 5, 10 & Intel Rapid Storage Technology 1 x M.2 (M Key) Socket: Supports M.2 Type: 2242/ 2260/ 2280 SSD module Supports PCIe 3.0 x4 (32Gb/s) & SATA III (6Gb/s) SSD LAN: Intel I219V, 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability AUDIO CODEC: Realtek ALC897 USB: 4 x USB 3.2 (Gen1) ports: (2 on rear I/Os and 2 via internal headers) 6 x USB 2.0 ports: (4 on rear I/Os and 2 via internal headers) EXPANSION SLOT: 2 x PCIe 3.0 x1 Slot 1 x PCle 3.0/ 4.0 x16 Slot (x16 mode) *The PCle 4.0 only depends on Rocket Lake CPUs. 7.1 Channels, High Definition Audio REAR I/O: 4 x SATA III Connector (6Gb/s) 1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports) 1 x USB 2.0 Header (each header supports 2 USB 2.0 ports) 1 x 8-Pin Power Connector 1 x 24-Pin Power Connector 1 x CPU Fan Connector 1 x System Fan Connector 1 x Front Panel Header 1 x Front Audio Header 1 x Clear CMOS Header 1 x COM Port Header H/W MONITORING: CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control CPU/DDR Voltage Monitoring
