MB AM5 B850 TUF GAMING PLUS WIFI ASUS 4xDDR5 8000Mhz (O.C), DP,HDMI,PCI-Ex16 5.0,2xPCI-Ex4 4.0,PCI-Ex1 3.0,3xM.2,4xSATA3,BT 5.3, 90MB1J30-M0EAY0

Опис

Model name: ASUS B850 PLUS WIFI Specifications: CPU: AMD Socket AM5 for AMD Ryzen™ 9000, 8000 & 7000 Series Desktop Processors Chipset: AMD B850 Chipset Memory: 4 x DIMM slots, max. 256GB DDR5 Supports up to 8000+MT/s (OC) ECC & Non-ECC Un-buffered DIMM Dual channel memory architecture Supports AMD EXPO™ & ASUS AEMP Graphics: 1 x DisplayPort (max. 8K@30Hz, DisplayPort 1.4) 1 x HDMI™ port (max. 4K@60Hz, HDMI 2.1) * Graphics specifications vary depending on CPU type Expansion Slots: Ryzen™ 9000 & 7000: 1 x PCIe 5.0 x16 slot (x16 mode) Ryzen™ 8000: 1 x PCIe 4.0 x16 slot (x8/x4 mode) B850 Chipset: 1 x PCIe 4.0 x16 slot (x4 mode) 2 x PCIe 4.0 x1 slots Storage: Total: 3 x M.2 slots + 4 x SATA 6Gb/s ports M.2_1: PCIe 5.0 x4 (Ryzen 9000/7000) / PCIe 4.0 x4 (Ryzen 8000) M.2_2: PCIe 4.0 x4 (Ryzen 9000/7000) / PCIe 4.0 x4/x2 (Ryzen 8000) M.2_3 (chipset): PCIe 4.0 x4 (shared with PCIEX16(G4)) 4 x SATA 6Gb/s ports RAIDXpert2: Ryzen 9000: RAID 0/1/5/10 Ryzen 8000: RAID 0/1 Ryzen 7000: RAID 0/1/10 Ethernet: Realtek 2.5Gb Ethernet with TUF LANGuard Wireless & Bluetooth: Wi-Fi 7 (802.11be), 2x2 MU-MIMO Supports 2.4/5/6GHz frequency bands 160MHz bandwidth, up to 2.9Gbps transfer rate Bluetooth® v5.4 USB: Rear (10 ports): 1 x USB 20Gbps (Type-C) 3 x USB 10Gbps (Type-A) 4 x USB 5Gbps (Type-A) 2 x USB 2.0 (Type-A) Front (7 ports): 1 x USB 10Gbps connector (Type-C) 1 x USB 5Gbps header (2 ports) 2 x USB 2.0 headers (4 ports) * USB Type-C® power delivery output: max. 5V/3A Audio: Realtek ALC1220P 7.1 Surround HD Audio CODEC Impedance sense for front/rear headphone outputs Integrated amplifier for headphones/speakers Supports Jack-detection, Multi-streaming, Front Panel Jack-retasking 120 dB SNR playback, 113 dB SNR recording Up to 32-Bit/192 kHz playback Audio Features: Audio shielding, premium capacitors, dedicated PCB layers, de-pop circuit Back Panel I/O: 1 x USB 20Gbps (Type-C) 3 x USB 10Gbps (Type-A) 4 x USB 5Gbps (Type-A) 2 x USB 2.0 (Type-A) 1 x DisplayPort 1 x HDMI™ 1 x Wi-Fi module 1 x Realtek 2.5Gb Ethernet port 5 x Audio jacks 1 x BIOS FlashBack™ button Internal I/O Connectors: Cooling: 1 x CPU Fan, 1 x CPU OPT Fan, 1 x AIO Pump, 4 x Chassis Fan Power: 1 x 24-pin ATX, 2 x 8-pin CPU Storage: 3 x M.2 slots, 4 x SATA 6Gb/s USB: 1 x USB 10Gbps Type-C, 1 x USB 5Gbps header (2 ports), 2 x USB 2.0 headers (4 ports) Misc: 3 x ARGB Gen 2 headers, Clear CMOS, Chassis Intrusion, COM Port, Front Audio, System Panel, Thunderbolt™ (USB4®) header BIOS: 256 Mb Flash ROM, UEFI AMI BIOS Manageability: WOL by PME, PXE Operating System: Windows 11 Form Factor: ATX (30.5 cm x 24.4 cm)
