MB 1151 B365M-HDV ASROCK 2xDDR4 2666Mhz, VGA, DVI-D, HDMI, 1xPCIex16, 1xPCIex1, 1xM.2, 6xSATAIII, 6xUSB3.1, 2xUSB 2.0, 7.1 CH HD Audio 90-MXB9R0-A0UAYZ

Опис

Model Name: ASROCK B365M-HDV Specification : CPU Support: Supports 9th and 8th Gen Intel® Core™ Processors (Socket 1151) Chipset: Intel® B365 Memory: Dual Channel DDR4 Memory Technology 2 x DDR4 DIMM Slots Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory Supports ECC UDIMM memory modules (operate in non-ECC mode) Max. capacity of system memory: 32GB Supports Intel® Extreme Memory Profile (XMP) 2.0 128Mb AMI UEFI Legal BIOS with multilingual GUI support Graphics: Supports Intel® UHD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 Three graphics output options: D-Sub, DVI-D and HDMI Supports Triple Monitor Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz Supports HDCP 2.2 with DVI-D and HDMI 1.4 Ports Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port Audio: 7.1 CH HD Audio (Realtek ALC887 Audio Codec) Supports Surge Protection ELNA Audio Caps LAN: Gigabit LAN 10/100/1000 Mb/s Giga PHY Intel® I219V, Supports Wake-On-LAN, Supports Lightning/ESD Protection Supports Energy Efficient Ethernet 802.3az, Supports PXE Wireless LAN: Slots: 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode) 2 x PCI Express 3.0 x1 Slots (Flexible PCIe) Storage: 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid Storage Technology 17), NCQ, AHCI and Hot Plug 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) Connectors: 1 x Print Port Header, 1 x COM Port Header, 1 x TPM Header 1 x Chassis Intrusion and Speaker Header 1 x CPU Fan Connector (4-pin) 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) 1 x 24 pin ATX Power Connector, 1 x 8 pin 12V Power Connector 1 x Front Panel Audio Connector, 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection) Rear Panel I/O: 1 x PS/2 Mouse/Keyboard Port, 1 x D-Sub Port, 1 x DVI-D Port 1 x HDMI Port, 2 x USB 2.0 Ports (Supports ESD Protection), 4 x USB 3.1 Gen1 Ports 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI: ASRock A-Tuning ASRock EZ Mode, ASRock Full HD UEFI, ASRock My Favorites in UEFI Form Factor: Micro ATX Form Factor: 8.9-in x 7.4-in, 22.6 cm x 18.8 cm OS Support: Microsoft Windows® 10 64-bit / 11 64-bit Certifications: FCC, CE, ErP/EuP ready (ErP/EuP ready power supply is required)
