MB AM5 B850 EAGLE WIFI6E GIGABYTE 4xDDR5 8200Mhz (O.C), DP, HDMI, PCI-Ex16 4.0, 3xPCI-Ex16 3.0, 3xM.2, 4xSATA3, Wi-Fi 6E, BT 5,3

Опис

Model Name: GIGABYTE B850 EAGLE WIFI6E Specification : CPU AMD Socket AM5, support for: AMD Ryzen™ 9000 Series Processors AMD Ryzen™ 8000 Series Processors AMD Ryzen™ 7000 Series Processors Chipset AMD B850 Memory Support for DDR5 8200(O.C) ... 4400 MT/s memory modules 4 x DDR5 DIMM sockets supporting up to 256 GB Dual channel memory architecture Support for non-ECC Un-buffered DIMM Support for AMD EXPO™ and XMP modules Onboard Graphics 1 x DisplayPort, up to 3840x2160@144 Hz 1 x HDMI port, up to 4096x2160@60 Hz Audio Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel LAN Realtek® GbE LAN chip (1 Gbps) Wireless Communication module Intel® Wi-Fi 6E AX210 Realtek® Wi-Fi 6E RTL8852CE Expansion Slots 1 x PCIe x16 from CPU (varies by processor) 3 x PCIe x1 from chipset (PCIe 3.0) Storage Interface 3 x M.2 connectors (varied PCIe versions) 4 x SATA 6Gb/s connectors RAID 0, 1, 5, 10 for NVMe RAID 0, 1, 10 for SATA USB CPU: 1 x USB-C (Gen1), 2 x USB 3.2 Gen2 Type-A Chipset: USB-C (Gen1), 4 x USB 3.2 Gen1, 4 x USB 2.0 Chipset+Hub: 4 x USB 2.0 via headers Internal I/O Connectors Power, fan, RGB, M.2, SATA, USB headers, TPM, buttons, jumpers Back Panel Connectors DisplayPort, HDMI, USBs, RJ-45, PS/2, audio jacks, Q-Flash I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage, Temperature, Fan speed, Water flow, Warnings BIOS 1 x 256 Mbit flash AMI UEFI BIOS (PnP, DMI, SM BIOS, ACPI) Bundled Software Norton® Internet Security (OEM) LAN bandwidth management Operating System Windows 11 64-bit Windows 10 64-bit Form Factor ATX; 30.5cm x 24.4cm
