PSU 1200W BE QUIET! DARK POWER 14 w/PCIe 5.1, 80 Plus TITANIUM FULL MODULAR, BP021EU

Опис

Model name: BE QUIET! DARK POWER 14 Specification : Cables and connectors Modular cables: ✓ Sleeved cables: ✓ Flat cables: ✓ Maximum cable length (cm): 105 Cable length to motherboard (cm): 60 No. of cables: 11 ATX-Motherboard (20+4-pin): 1 P4+4 (CPU): 1 P8 (CPU): 1 12V-2x6 cables: 2 PCI-e 6+2-pin (GPU): 4 SATA: 13 PATA: 2 General Continuous power (W): 1200 Peak power (W): 1300 Form factor: ATX 3.1 Form factor EPS 12V: Version 2.92 Topology: Full bridge + LLC + SR + DC/DC Digitally controlled: ✓ Voltage (Vac): 100 - 240 Frequency (Hz): 50 - 60 Input current (A): 7 Power factor at 100% load: >0.98 Modern standby: ✓ Power consumption in standby (W): Average life time (h / 25°C): >100,000 Operating temperature up to (°C): 40 Efficiency 80 PLUS certification: Titanium Efficiency (%) at 230V, 2% load: 75.3 Efficiency (%) at 230V, 10% load: 92.2 Efficiency (%) at 230V, 20% load: 94.8 Efficiency (%) at 230V, 50% load: 95.4 Efficiency (%) at 230V, 100% load: 93.1 Fan and cooling technology Cybenetics Noise Rating: Titanium Fan: Silent Wings Fan size (mm): 135 Bearing technology: FDB Motor technology: 6-pole fan motor Max. fan speed (rpm): 2100 dB(A) at 10% load: 8 dB(A) at 20% load: 8 dB(A) at 50% load: 8.3 dB(A) at 100% load: 21.1 Output Multi-rail operation (12V rails): 1 Overclocking key: ✓ +3.3V (A): 25 +5V (A): 24 +12V1 (A): 33 +12V2 (A): 33 +12V3 (A): 45 +12V4 (A): 45 +12V5 (A): N/A +12V6 (A): N/A -12V (A): 0.5 +5Vsb (A): 3 Max. combined power 12V (W): 1200 Max. combined power 12V-2x6 (W): 600 Max. combined power 3.3V + 5V (W): 120 Hold-up time at 80% load (ms): 19.5 Power good signal (ms): 100 - 150 Protection OTP (over temperature protection): ✓ OCP (over current protection): ✓ OPP (over power protection): ✓ SCP (short circuit protection): ✓ OVP (over Voltage protection): ✓ UVP (under Voltage protection): ✓ SIP (Surge & Inrush protection): ✓
